Brug for hjælp? Ring til os påSelvvulkaniserende tape 50mm 8000 volt - 10m sort 1 rl/stk
5710190-277018
Lagerstatus:
Lagerstatus:
Usage:
Self-fusing, butyl rubber tape, widely used for the electrical insulation, protection, sealing, splicing and termination of 6 to 22 kV cables.
We have eliminated the conventional need for a liner thereby reducing the time required to apply the tape.
| Values | Test methods | ||
|---|---|---|---|
| Thickness | 0.5 mm | ASTM D 1000 | |
| Tensile strength 23 °C | 3.2 N/mm² | ASTM D 1373 (500mm/min) | |
| Tensile strength 100 °C, 96 hrs | 3.0 N/mm² | ASTM D 1373 | |
| 100% Modulus 23 °C | 1.3 N/mm² | ASTM D 1373 | |
| 100% Modulus 100 °C, 96 hrs | 1.3 N/mm² | ASTM D 1373 | |
| Elongation 23 °C | 550% | ASTM D 1373 | |
| Elongation 100 °C, 96 hrs | 570% | ASTM D 1373 | |
| Brittle point | -60 °C | ||
| Breakdown voltage | 44 kV/mm | ||
| Volume resistivity | 2 x 1017 Ω/cm | ASTM D 1373 | |
| Dielectric dissipation factor | 0.04% | ||
| Dielectric constant | 2.6 | ASTM D 150 | |
| Power factor (60 Hz) | 0.05-0.08% | ASTM D 1373 | |
| Ozone resistance (0.02%, 24 hrs) | Good | ASTM D 470 |
